National Stock Numbers (NSN)

Last Updated: 8 months ago

Zip-On®

Polyvinylchloride (PVC) Jacket with Track Closure
Size Shape NSN Old ZT Part Number ZT Part Number Closure
0.375” Round 5970-00-851-4288 ZTZ-0375-GP-20-B

ZT99-16-005-0.375

Z-Track
0.5” Round 5970-00-997-8668 ZTZ-0500-GP-20-B ZT99-16-005-0.5 Z-Track
0.625” Round 5970-00-080-1421 ZTZ-0625-GP-20-B

ZT99-16-005-0.625

Z-Track
0.625” Round 5970-00-995-0876 ZTZ-0625-GP-20-B

ZT99-16-005-0.625

Z-Track
0.875” Round 4710-01-330-0085 ZTZ-0875-GP-20-B

ZT99-16-005-0.875

Z-Track
1.0” Round 5970-01-041-3881 ZTZ-1000-GP-20-B

ZT99-16-005-1.0

Z-Track

Zip-On® (63)

Polyvinylchloride (PVC) Jacket with Track Closure
Size Shape NSN Old ZT Part Number ZT Part Number Closure Comments
0.375” Round 5970-01-201-4142 ZTZ-0375-63-20-B ZT99-16-052-0.375-B-B Z-Track Inside Overlap
0.5” Round 5970-00-725-8685 ZTZ-0500-63-20-B ZT99-16-052-0.5-B-B Z-Track Inside Overlap
0.625” Round 5970-00-725-8684 ZTZ-0625-63-20-B ZT99-16-052-0.625-B-B Z-Track Inside Overlap
0.75” Round 5970-01-200-7995 ZTZ-0750-63-20-B ZT99-16-052-0.75-B-B Z-Track Inside Overlap
0.875” Round 5970-01-204-1168 ZTZ-0875-63-20-B ZT99-16-052-0.875-B-B Z-Track Inside Overlap
1.0” Round 5970-00-478-0049 ZTZ-1000-63-20-B ZT99-16-052-1.0-B-B Z-Track Inside Overlap
1.125” Round 5970-01-201-3388 ZTZ-1125-63-20-B ZT99-16-052-1.125-B-B Z-Track Inside Overlap
1.25” Round 5970-00-038-7469 ZTZ-1250-63-20-B ZT99-16-052-1.25-B-B Z-Track Inside Overlap
1.5” Round 5970-01-200-7994 ZTZ-1500-63-20-B ZT99-16-052-1.5-B-B Z-Track Inside Overlap
1.75” Round 5970-01-201-2715 ZTZ-1750-63-20-B ZT99-16-052-1.75-B-B Z-Track Inside Overlap
2.0” Round 5970-01-219-7342 ZTZ-2000-63-20-B ZT99-16-052-2.0-B-B Z-Track Inside Overlap
3.875 Round 5970-00-177-6301 ZTZ-3875-63-20-B ZT99-16-052-3.875-B-B Z-Track Inside Overlap
0.5” Round 5970-00-080-1424 ZTR-0500-63-20-B ZT99-16-049-0.5-B-B R-Track Inside Overlap
2.0” Flat 5970-00-389-4453 ZTZ-2000-ZRP-63-20-B ZT99-16-225-2.0-B-B Z-Track Inside Overlap
2.0” Flat 5970-01-114-3033 ZTZ-2000-ZRP-63-20-B ZT99-16-225-2.0-B-B Z-TRack Inside Overlap
3.875” Flat 5970-01-201-3387 ZTZ-3875-ZRP-63-20-B ZT99-16-225-3.875-B-B Z-Track Inside Overlap
0.625” Round 5970-01-310-8842 ZTZ-0625-GP-20-B-OL ZT99-16-052-0.625-B-B Z-Track Inside Overlap
0.75” Round 5970-01-339-9758 ZTZ-0750-GP-20-B-OL ZT99-16-052-0.75-B-B Z-Track Inside Overlap
1.125” Round 5970-01-311-8844 ZTZ-1125-GP-20-B-OL ZT99-16-052-1.125-B-B Z-Track Inside Overlap
1.25” Round 5970-01-320-4797 ZTZ-1250-GP-20-B-OL ZT99-16-052-1.25-B-B Z-Track Inside Overlap

Zip-On® (PFR)

Extremely Flexible Polyurethane Jacket with Track Closure
Size Shape NSN Old ZT Part Number ZT Part Number Closure Comment
0.375” Round 5970-01-544-5787 ZTZ-0375-PFR-18-B ZT99-16-039-0.375-B-B Z-Track Inside Overlap
0.375” Round 5970-01-157-4335 ZTZ-0375-PFR-20-B ZT99-16-078-0.375-B-B Z-Track Inside Overlap
0.5” Round 5970-01-187-5282 ZTZ-0500-PFR-18-B ZT99-16-078-0.5-B-B Z-Track Inside Overlap
0.875” Round 5970-01-261-2544 ZTZ-0875-PFR-20-B ZT99-16-078-0.875-B-B Z-Track Inside Overlap
1.25” Round 5970-01-269-3409 ZTZ-1250-PFR-18-B ZT99-16-078-1.25-B-B Z-Track Inside Overlap
2.0” Round 5970-00-140-7166 ZTZ-2000-PFR-18-B ZT99-16-078-2.0-B-B Z-Track Inside Overlap

Zip-On® (DVH)

Polyvinylchloride Coated Fabric Jacket with Track Closure
Size Shape NSN Old ZT Part Number ZT Part Number Closure Comment
2.625” Round 5970-01-285-3351 ZTZ-2625-DVH-20-B ZT99-16-033-2.625-B-B Z-Track Inside Overlap

Zip-On® (VNH)

Mil-Spec PVC Coated Nylon Jacket Track Closure
Size Shape NSN Old ZT Part Number ZT Part Number Closure Comment
7” Round 5970-01-035-8955 ZTZ-7000-VNH-B

ZT99-16-064-7.0-B

Z-Track Inside Overlap

Hook-It® (VNH)

Mil-Spec PVC Coated Nylon Jacket Hook-N-Loop Closure
Size Shape NSN Old ZT Part Number ZT Part Number Closure
1” Round 5970-01-564-9268 ZTX3-1000-VNH-23-B

ZT97-13-006-1.0-B

Hook-andLoop

Zip-Shield® (SHX)

Protective Jacket w/ Pressure Track and SHX4 Mesh Shielding
Size Shape NSN Old ZT Part Number ZT Part Number Closure
0.5” Round 5970-01-115-7793 ZTZ-0500-SHX4-63-20-B

ZT97-17-066-0.5-B-B

Z-Track
0.625” Round 5970-01-145-1501 ZTZ-0625-SHX4-63-20-B ZT97-17-066-0.625-B-B Z-Track
0.75” Round 5970-01-091-4054 ZTZ-0750-SHX4-63-20-B

ZT97-17-066-0.75-B-B

Z-Track
0.75” Round 5970-01-082-0299 ZTZ-0750-SHX4-GP-20-B

ZT97-17-066-0.75-B-B

Z-Track
0.875” Round 5970-01-144-5758 ZTZ-0875-SHX4-63-20-B ZT97-17-066-0.875-B-B Z-Track
1.25” Round 5970-01-146-0151 ZTZ-1250-SHX4-63-20-B ZT97-17-066-1.25-B-B Z-Track
1.5” Round 5970-01-133-5495 ZTZ-1500-SHX4-63-20-B ZT97-17-066-1.5-B-B Z-Track
1.75” Round 5970-01-118-5103 ZTZ-1750-SHX4-63-20-B ZT97-17-066-1.75-B-B Z-Track

Zip-Shield® (SH1)

Protective Jacket w/ Pressure Track, Aluminum Foil Shielding & 15 AWG Ground Wire



Size Shape NSN Old ZT Part Number ZT Part Number Closure
0.625” Round 5970-01-396-5361 ZTZ-0625-SH1-63-10-B

ZT97-17-004-0.625-B-B

Z-Track
0.75” Round 5970-01-386-5107 ZTZ-0750-SH1-63-10-B

ZT97-17-004-0.75-B-B

Z-Track

Zip-Mesh® (Cu)

EMI Shielding Tape, SnCu Mesh/Copper Foil, Adhesive Backed
Size Shape NSN Old ZT Part Number ZT Part Number Closure
1” W Tape 5999-21-912-0008 Zip-Mesh-Cu Tape

ZT98-03-002-1.0

Adhesive

PRT® (ES-135)

Our proven PRT® heat shrink wrap with additional hot-melt, water-blocking adhesive (up to 135°C/275°F)
Size Shape NSN Old ZT Part Number ZT Part Number Closure
0.040”-0.075” Round 5970-01-611-7759 ZT03-04-010-01

ZT03-04-010-01-X600.0

Adhesive
0.076”-0.125” Round 5970-01-611-8106 ZT03-04-010-03

ZT03-04-010-03-X600.0

Adhesive
0.126”-0.174” Round 5970-01-611-8111 ZT03-04-010-05

ZT03-04-010-05-X600.0

Adhesive
0.175”-0.25” Round 5970-01-611-8118 ZT03-04-010-07

ZT03-04-010-07-X600.0

Adhesive
0.25”-0.37” Round 5970-01-611-8178 ZT03-04-010-09

ZT03-04-010-09-X600.0

Adhesive
0.38”-0.49” Round 5970-01-611-8206 ZT03-04-010-11 ZT03-04-010-11-X600.0 Adhesive
0.50”-0.62” Round 5970-01-611-8240 ZT03-04-010-13 ZT03-04-010-13-X600.0 Adhesive
0.63”-0.74” Round 5970-01-611-8252 ZT03-04-010-15 ZT03-04-010-15-X600.0 Adhesive
0.75”-0.87” Round 5970-01-611-8263 ZT03-04-010-17 ZT03-04-010-17-X600.0 Adhesive
0.88”-0.99” Round 5970-01-611-8434 ZT03-04-010-19 ZT03-04-010-19-X600.0 Adhesive
1.0”-1.12” Round 5970-01-611-8441 ZT03-04-010-21 ZT03-04-010-21-X600.0 Adhesive
1.13”-1.24” Round 5970-01-611-8504 ZT03-04-010-23 ZT03-04-010-23-X600.0 Adhesive
1.25”-1.37” Round 5970-01-611-8541 ZT03-04-010-25 ZT03-04-010-25-X600.0 Adhesive
1.38”-1.49” Round 5970-01-611-8558 ZT03-04-010-27 ZT03-04-010-27-X600.0 Adhesive
1.50”-1.62” Round 5970-01-611-8570 ZT03-04-010-29 ZT03-04-010-29-X600.0 Adhesive
1.63”-1.74” Round 5970-01-611-8582 ZT03-04-010-31 ZT03-04-010-31-X600.0 Adhesive

PRT®

Fix chafed wires with PRT® heat shrink wrap, an in-service, made from MIL-SPEC tubing, wrap-around heat shrink that protects electrical systems, assembled wires, and cables.
Size Shape NSN Old ZT Part Number ZT Part Number Closure
0.125”-0.187” Round 5970-01-508-5738 PRT-1

ZT98-04-016-1-B-X600.0

Adhesive
0.188”-0.249” Round 5970-01-508-5746 PRT-2

ZT98-04-016-2-B-X600.0

Adhesive
0.25”-0.37” Round 5970-01-508-5754 PRT-3

ZT98-04-016-3-B-X600.0

Adhesive
0.38”-0.49” Round 5970-01-500-6558 PRT-4

ZT98-04-016-4-B-X600.0

Adhesive
0.38”-0.49” Round 5975-01-632-4148 PRT-4

ZT98-04-016-4-B-X600.0

Adhesive
0.50”-0.62” Round 5970-01-500-6564 PRT-5

ZT98-04-016-5-B-X600.0

Adhesive
0.63”-0.74” Round 5970-01-500-6563 PRT-6

ZT98-04-016-6-B-X600.0

Adhesive
0.75”-0.87” Round 5970-01-508-5759 PRT-7

ZT98-04-016-7-B-X600.0

Adhesive
0.88”-0.99” Round 5970-01-508-5762 PRT-8

ZT98-04-016-8-B-X600.0

Adhesive
1.0”-1.12” Round 5970-01-508-8888 PRT-9

ZT98-04-016-9-B-X600.0

Adhesive
1.13”-1.24” Round 5970-01-508-5980 PRT-10

ZT98-04-016-10-B-X600.0

Adhesive
1.25”-1.37” Round 5970-01-508-5982 PRT-11

ZT98-04-016-11-B-X600.0

Adhesive
1.38”-1.49” Round 5970-01-508-6893 PRT-12

ZT98-04-016-12-B-X600.0

Adhesive
1.50”-1.62” Round 5970-01-508-5895 PRT-13

ZT98-04-016-13-B-X600.0

Adhesive
1.63”-1.74” Round 5970-01-508-5896 PRT-14

ZT98-04-016-14-B-X600.0

Adhesive

Custom Solutions

NSN Old ZT Part Number ZT Part Number Description
5999-01-290-0592 6122943 ZT98-06-002 Custom Phalanx Gun Mount EMI Shield
5999-01-598-4543 10025456 ZT09-06-004 Custom Manifold EMI Shield
8A-1195-LL-JFO-0582 N/A ZT96-15-006 Custom Pre-Cut Z-5080 Panels 30” x 41”
5970-01-588-2843 1EFH8S0CN10025455 ZT09-07-012 Custom Wiper Motor EMI Shield Patch
5975-01-470-3560 ZTX3-2000-PFR--18-B ZT98-12-008 Custom PFR-18 Velcro Closure, Round 2” x 60”
5999-01-505-4743 7327573-01 ZT02-15-003-01 Custom SHX4 Grounding Pad
5999-01-505-4745 7327573-03 ZT02-15-003-03 Custom SHX4 Grounding Pad
5975-01-528-7356 5PTV4211-101 ZT03-04-009-01 Custom "Heat Wrap" Shapes
5975-01-528-7358 5PTV4211-103 ZT03-04-009-03 Custom "Heat Wrap" Shapes
5975-01-528-7359 5PTV4211-105 ZT03-04-009-05 Custom "Heat Wrap" Shapes
5975-01-566-8645 5PTV4211-109 ZT03-04-009-09 Custom "Heat Wrap" Shapes
5340-01-587-7203 N/A ZT05-06-004-01 Custom Shielded Cone
5340-01-587-7259 N/A ZT05-06-004-03 Custom Shielded Cone
5340-01-587-7261 N/A ZT05-06-004-05 Custom Shielded Cone

Track Installation Tools

NSN Old ZT Part Number ZT Part Number Closure Tool For
5120-01-343-9112 ZTZ-SP

ZTZ-SP

Z-Track
5210-01-159-6957 ZTZ-SP ZTZ-SP Z-Track
5120-01-019-4115 SLR SLR R-Track
