Polyamide Hot Melt (135) Adhesive

Name: Polyamide Hot Melt (135) Adhesive
Brand: zippertubing
Availability: InStock

Material Specification: 8205 RoHS

Raw materials are not available for standalone purchase; instead, they are intended to be integrated into a tailor-made, custom-engineered solution. Explore the possibilities below or contact an engineer to start your custom application today!

Overview

Utilized for blocking against water, oils, and most fluids
Ideal to pair with polyolefin, PVC, or EVA-type heat shrinkable tubing
Creates no corrosion of copper and aluminum metal substrates

This hot melt is a polyamide polymer material that creates no corrosion of copper and aluminum metal substrates. The polyamide hot melt is ideal to pair with polyolefin, PVC, or EVA-type tubing to create a water blocking heat shrink solution. The polyamide hot melt is installed with a standard heat gun, and can handle temperatures up to 275°F (135°C).

Specifications

REACH: Compliant

Elongation: 350%

Material: Polyamide Polymer

Color: Amber (semi-transparent)

Thickness: 0.008"

Maximum Operating Temperature: 275°F

Minimum Operating Temperature: -67°F

Water Absorption: 0.5% maximum

RoHS: RoHS-10

Shelf Life: 60 Months

Softening Temp: 284°F

Softening Temp Variance: +/- 9°F

Flexibility: Good

Specifications subject to change without notice. All statements and technical information contained herein are based on tests we believe to be reliable, but the accuracy or completeness is not guaranteed under all circumstances. Before using Zippertubing® products, the user shall determine suitability for the intended use, and user assumes all responsibility for improper selection. Published attenuation values of Zippertubing® shielding have been verified by laboratory testing of the respective shielding materials. Actual installed attenuation values may differ due to installation techniques and final assembly operation parameters which are beyond the control of Zippertubing®. Actual attenuation values can only be determined by the end user testing the completed assembly. U.S. and International Patents and patents pending. © The Zippertubing® Company, Chandler, Arizona.

Polyamide Hot Melt (135) Adhesive

Material Sprcification: 8205

Utilized for blocking against water, oils, and most fluids
Ideal to pair with polyolefin, PVC, or EVA-type heat shrinkable tubing
Creates no corrosion of copper and aluminum metal substrates

WARNING: Raw materials are not sold separately, please contact the sales department for any special requirements.

SPECIFICATIONS

REACH: Compliant

Elongation: 350%

Material: Polyamide Polymer

Color: Amber (semi-transparent)

Thickness: 0.008"

Maximum Operating Temperature: 275°F

Minimum Operating Temperature: -67°F

Water Absorption: 0.5% maximum

RoHS: RoHS-10

Shelf Life: 60 Months

Softening Temp: 284°F

Softening Temp Variance: +/- 9°F

Flexibility: Good

DESCRIPTION

This hot melt is a polyamide polymer material that creates no corrosion of copper and aluminum metal substrates. The polyamide hot melt is ideal to pair with polyolefin, PVC, or EVA-type tubing to create a water blocking heat shrink solution. The polyamide hot melt is installed with a standard heat gun, and can handle temperatures up to 275°F (135°C).
